Air mesh and spacer fabric double needle bed raschel machine

Place of Origin : Jiangsu, China

Brand Name : ZYTT

Packaging Details : Wooden package

Supply Ability : 100 Set/Sets per Month

Price : $68,000.00/sets 1-2 sets

Certification : CE

MOQ : 1 set

Delivery Time : 30 days

Model Number : RD6 DPLM12/3

Applicable Industries : Manufacturing Plant, Shoemaking factory, Net making factory

Showroom Location : India, Italy

Video outgoing-inspection : Provided

Machinery Test Report : Provided

Marketing Type : New Product 2022

Warranty of core components : 1 Year

Core Components : PLC, Engine, Bearing, Gearbox, Motor, Pressure vessel, Gear, Pump

Condition : New

Type : warp knitting machine

Application : air mesh and spacer, Textile Industry

Production Capacity : max speed 800rpm

Dimension(L*W*H) : 5900x5500x3300mm

Weight : 12000 KG

Power : 4KW

Warranty : 1 Year

Key Selling Points : High Productivity

Needle type : Latch Needle

Gauge : E16 E18 E22 E24 E26 E28

Number of bars : 5 bars 6 bars

Distance between knocking-over bars : 3-12mm

Working width : 90" 100" 110" 138"

Max speed : 800rmp

Port : ningbo qingdao shanghai

Contact Now

ZYTT-RD6 DPLM12/3 Air mesh and spacer fabric double needle bed raschel machine
Features
Adopt oil immersed cam and eccentric linkage bar system
Looping part adopt four-bar mechanism
Short stoke latch needles
EBA let-off
Machine Specification & Advantages
Needle type
Latch Needle
Gauge
E16 E18 E22 E24 E26 E28
Number of bars
5 bars 6 bars
Distance between knocking-over bars
3-12mm
Working width: Diameter of Speed Roller
90” 100” 100” 110” 138”
Power of Main Motor
4KW
Max speed
800rmp
Weight
12000
Machine Display
Air mesh and spacer fabric double needle bed raschel machine
Machine Application
This machinemainly weave air mesh and sandwich fabric, three-ply spacer fabric, used in shoes, backing strap, lining cushion,and so on.
Air mesh and spacer fabric double needle bed raschel machine
